Features:
- The arm pipe and vertical shaft parts (which greatly influence sound quality) are made from stainless steel.
- Along the main conduction tube we have reproduced a material close to stainless steel supplement, using brass with a tough chrome plating
- The fulcrum is strongly supported with radial bearings
- The inside force canceler, Arm Resting Device and Arm Lifting Device are insulated with ABS resin, and reduces reverberation distortion
Specification:
| MODEL |
MH-9B |
MH-10B |
| Balancing |
Static Balancing |
| Total Length (*1) |
252mm |
277mm |
| Effective Length (*2) |
229mm |
254mm |
| Practical Length (*3) |
214mm |
239mm |
| Offset Angle |
23 ° |
22 ° |
| Adaptable cartridge weight(incl headshell）(*4) |
11～28g |
11～26g |
| Total weight |
700g |
730g |
| Overhung |
15mm |
15mm |
| Tracking weight range |
0.25g (Minimum scale) – over 6g (3g/360 °rotation) |
| Adjustable height (*5) |
41mm～ |
| Headshell weight |
option |
| Shaft dimensions to mounting base |
16mmΦ |
| Mounting hole size |
24mmΦ |
| Fixing depth size |
Up to 29mmt (Another size is available) |
(*1) : From counter weight shaft end headshell terminal.
(*2) : From centre of tonearm Base to stylus tip.
(*3) : From centre of tonearm Base to centre of turntable)
(*4) : When the sub weight is attached, you can use a head shell and cartridge with a combined weight up to 40g.
(*5) : From plinth surface to horizontal height of arm tube
|
|
